Ubiquiti BM5-Ti Bullet M5 Titanium Outdoor 5GHz WiFi Access Point (150Mbps N)

Turn any 5.8GHz antenna into a PtP or PtMP bridge
Connect two remote locations on the one network
Share Internet connection between buildings, remote sites, etc
Up to 600mW output power, +100Mbps capable
POE Injector & 240V AC Adapter included.

Category: Ubiquiti Wireless Tag: Ubiquiti BM5-Ti Bullet M5 Titanium Outdoor 5GHz WiFi Access Point (150Mbps N)

Description

Ubiquiti BM5-Ti Bullet M5 Titanium Outdoor 5GHz WiFi Access Point (150Mbps N)

The Ubiquiti BM5-Ti Bullet M5 Titanium Outdoor 5GHz WiFi Access Point (150Mbps N) is the latest version of the popular Ubiquiti Bullet. Like its predecessor, this Ubiquiti Bullet M5 Titanium is a wireless radio with an integrated N-Type RF connector that can be directly plugged in to any antenna to create a powerful and robust outdoor Access Point, Client, or Bridge. The Ubiquiti Bullet M5 Titanium is engineered to survive extreme conditions and features an upgraded aluminium casing, weatherproof N-Type connection gasket, and water-tight cable gland to make it virtually bullet-proof.

Key Features

High Performance 5GHz 802.11n radio architecture.
Works with any suitable antenna, N Type connector.
Ubiquiti AirOS software for management.
Weatherproof Titanium external housing.
Power over Ethernet*.

Integrated airMAX Technology

The Ubiquiti Bullet M5 Titanium can instantly become a powerful TDMA BaseStation utilising Ubiquiti’s breakthrough airMAX technology. With airMAX, PtMP networks can scale gracefully while maintaining high throughput and low latency performance.

Zero-Variable Deployment

The Ubiquiti Bullet M5 Titanium eliminates the need to use RF cables and requires no special antenna or tools to install. No radio card / host board issues. No RF cable quality concerns. No mechanical stability concerns. No enclosure mounting requirements. With the Ubiquiti Bullet M5 Titanium, operators can just plug and go.

airOS

Ubiquiti airOS is an intuitive, versatile, highly developed Ubiquiti ï¬rmware technology. It is exceptionally intuitive and was designed to require no training to operate. Behind the user interface is a powerful ï¬rmware architecture which enables hi-performance outdoor multipoint networking.

*No power supply or POE injector included.

Standard warranty: 1-year

Specifications

System Information

Processor Specs Atheros MIPS 24KC, 400 MHz
Memory Information 32 MB SDRAM, 8 MB Flash
Networking Interface (1) 10/100 Ethernet Port

Regulatory / Compliance Information

Wireless Approvals FCC Part 15.247, IC RS210, CE
RoHS Compliance Yes

Physical / Electrical / Environmental

Dimensions 190 x 46 mm
Weight 196 g
Enclosure Characteristics Powder Coated Aluminium
Antenna Connector N-Type Connector (male)
Power Supply 24V, 0.5A PoE Adapter (included)
Power Method Passive Power over Ethernet (pairs 4, 5+; 7, 8 return)
Max. Power Consumption 7 Watts
Operating Temperature -40 to 80° C
Operating Humidity 5 to 95% Condensing
Shock and Vibration ETSI300-019-1.4

Software Information

Modes Station, Access Point, AP Repeater
Services SNMP, DHCP, NAT
Utilities Site Survey with Preferred SSID, Antenna Alignment Tool, Discovery Utility
Security WEP/WPA/WPA2
QoS 802.11e / WMM Support
Statistical Reporting Ethernet Activity, Uptime, Packet Success/Errors
